KHAN 9VDI
STUDIO QUALITY TUBE WARMTH
Utilizing a single 12AU7 in a unique 2-stage design that maximizes both the harmonic richness of the tube as well as powerful low-impedance output drive capability. The 9VDI is ideal for use with a number of instruments and sources, Bass guitar, keyboards, samplers, Acoustic guitar...
FEATURES
- All Tube Signal Path
- 1 x 12AU7 Tube
- 1/4" Instrument Input with 6dB Pad Switch
- 1/4" Instrument Thru "Tube Processed"
- Tube Driven Transformer Balanced XLR Line Output with Ground Lift
- High Headroom Gain Stage Design
- High Filtered Internal Power Supply
SPECS
- Input Impedance: 2.2M ohm
- Max Signal Input: 3v RMS (+10dB)
- Gain: -10dB to XLR Output
- Frequency Response: 8Hz - 120KHz +/- 1dB
- THD (1KHz 0dB Input): .75%
- Signal to Noise: -92dB
- Size 5 x 4 x 1 3/4
- 9VDC @ 500mA Power Requirement
- Universal 9V 1.2A power supply included
- Weight: 1lb
